China Off-Grid Solar System Three-Phase Series Suppliers, Manufacturers - Factory Direct Price

Product Description

Niyue® is Off-Grid Solar System Three-Phase Series manufacturers and suppliers in China who can wholesale Off-Grid Solar System Three-Phase Series, we can provide professional service and better price for you.

Off-Grid Solar System Three-Phase Series Features

Continuous, standard and stable pure sine wave with LCD display
The system can provide electricity produced by solar energy to loads directly
PV priority mode or AC priority mode is identified and swithched automatically
The system will act as UPS
The system build in stabilizer with AVR function
Integrated with inverter, solar controller inside, adopts 1 CPU control
UPS Auto-switched, self-recovery and unattended opertion functions

Parameter

Model No		GP-40000/3P	GP-50000/3P	GP-60000/3P
Basic Configuration (Adjustable)	Inverter	40KW/50KW/60KW
	Solar Panels	117pcs 345W Mono	156pcs 345W Mono	180pcs 345W Mono
	Battery	180pcs 2V500AHGELBattery	180pcs 2V 600AHGEL Battery	180pcs 2V800AHGEL Battery
Inverter Parameter	Rated Output Power	40000W	50000W	60000W
	DCInput Voltage	DC360V
	AC InputVoltage	220V/380V AC±10%
	Frequency	50Hz±0.5Hz
	Output Wave	Pure sine wave
	Transfer Efficiency	≥95%
	Packing Mterial	Wooden case
	Packing Size(MM)	810×960×1460mm	810×960×1460mm	1060×1260×1760mm
	G.W./CTN(KG(S))	395kg	440kg	580 kg
Solar Controller Parameter	Solar Controller Input Range	DC420V-DC650V
	Recommanded Input Voltage	DC480V
	Charging Current	120A	160A
	ChargingEfficiency	97%(Max)
	Charger Type	MPPT/PWM
	Maximum Input Power	42000W	56000W
AC Charging Parameter	ChargingCurrent	35A	35A	35A
	AC InputVoltage	AC285±5V-AC475±5V
	AC Input Frequency	50Hz±5Hz/60Hz±5Hz(Automatically tracking and adaptive)
Battery Parameter	Battery Type	GEL Battery
	Battery InputVoltage	360V
	Battery Capacity	500AH	600AH	800AH
Solar PanelParameter	Power Output	345W
	Voltage at Pmax	32.52V
	Current at Pmax	8.47A
	Open-CircuitVoltage	38.52V
	Short-Circuit Voltage	8.94A
