Factory Directly 10w 200w Led Highbay Light made in China. Niyue® is 10w 200w LED Street Light manufacturer and supplier in China.
1. The light fixture adopts die-cast aluminum to improve the heat dissipation efficiency, the appearance design is beautiful and exquisite, with small and thin volume;
2. Use high-strength tempered glass, light transmittance can be up to 95%, high lumen output, high CRI, multi color temperature, to meet a variety of lighting needs;
3. High lumen output, high visibility, multi-color temperature, to meet a variety of lighting needs
4. Green and environmental, long lifespan, impact resistance, strong shock
| Model | TG10DOB- Ⅱ | TG20DOB- Ⅱ | TG30DOB- Ⅱ | TG50DOB- Ⅱ | TG100DOB- Ⅱ | TG150DOB- Ⅱ | TG200DOB- Ⅱ |
| Power(w) | 10 | 20 | 30 | 50 | 100 | 150 | 200 |
| Input voltage | 100-240/50/60Hz | 100-240/50/60Hz | 100-240/50/60Hz | 100-240/50/60Hz | 100-240/50/60Hz | 100-240/50/60Hz | 100-240/50/60Hz |
| LED ChipType | 2835 | 2835 | 2835 | 2835 | 2835 | 2835 | 2835 |
| Light Efficiency | 90-100Lm/w | 90-100Lm/w | 90-100Lm/w | 90-100Lm/w | 90-100Lm/w | 90-100Lm/w | 90-100Lm/w |
| CCT | 2700-6000K | 2700-6000K | 2700-6000K | 2700-6000K | 2700-6000K | 2700-6000K | 2700-6000K |
| CRI | >70&80 | >70&80 | >70&80 | >70&80 | >70&80 | >70&80 | >70&80 |
| PF | ≥0.9 | ≥0.9 | ≥0.9 | ≥0.9 | ≥0.9 | ≥0.9 | ≥0.9 |
| IEC | Class I | Class I | Class I | Class I | Class I | Class I | Class I |
| Size: L*W*H(mm) | 102*80*26 | 120*95*28 | 161*121*30 | 202*156*30 | 270*210*38 | 322*231*38 | 385*281*40 |
| IP Class | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Working TEMP | -40℃~+50℃ | -40℃~+50℃ | -40℃~+50℃ | -40℃~+50℃ | -40℃~+50℃ | -40℃~+50℃ | -40℃~+50℃ |
| Life | 30000H | 30000H | 30000H | 30000H | 30000H | 30000H | 30000H |
1.Please use the correct power supply
2.The use of voltage can not exceed the specified range
3.Please read the product installation manual carefully before using
Niyue Light all rights reserved. Niyue Light does not make any representations or warranties regarding the accuracy or completeness of the information contained in this document,responsible for any actions made by this file information. The information provided in this document does not constitute any commercial agreement, nor does it form part of any quotation or contract, unless agreed by Niyue.
Widely used in stadium, wall, indoor parking, tunnels, storerooms, walkways lighting, etc
