Niyue® as a professional 166*83 Half cell 410w-450W Mono Poly solar Module manufacturer, you can rest assured to buy 166*83 Half cell 410w-450W Mono Poly solar Module from our factory and we will offer you the best after-sale service and timely delivery.
| Short Circuit Current Temperature Coefficiant %/℃ | 0.06 |
| Open Circuit Voltage Temperature Coefficient %/℃ | -0.34 |
| Maximum Power Temperature Coefficient %/℃ | -0.47 |
| Performance Warranty : 90%output ,12 years |
|
|
80%output, 25 years |
| Type Of Module | NB-410W | NB-420W | NB-440W | NB-450W |
| Maximum Power (W) | 410W | 420W | 440W | 450W |
| Tolerance(%) | ±3% | ±3% | ±3% | ±3% |
| Open Circuit Voltage (V) | 48.80 | 48.96 | 49.50 | 50.28 |
| Short Circuit Current (A) | 10.75 | 10.93 | 10.33 | 11.40 |
| Maximum Power Voltage (V) | 40.10 | 40.51 | 40.95 | 41.60 |
| Maximum Power Current (A) | 10.22 | 10.37 | 10.75 | 10.82 |
| Module Efficiency(%) | 18.86 | 19.30 | 20.24 | 20.70 |
| Solar Cell Efficiency(%) | 21.3 | 21.82 | 22.86 | 23.38 |
| Series Fuse Rating (A) | 20 | 20 | 20 | 20 |
| Terminal Box | IP65 | |||
| Maximum system voltage (V) | DC 1500V | |||
| Operating Temperature(℃) | -40℃--85℃ | |||
| Dimension | 2094 x 1038 x35 mm | |||
| Weight | 23.5kg/pc | |||
| Packing | 2pcs in one carton or 30pcs per pallet | |||
