Niyue® warmly welcome you to wholesale 270-300W Mono Poly solar Module from our factory. Our products are CE certified and currently have a large amount of factory inventory. We will provide you with good service and factory discounted prices.
| Short Circuit Current Temperature Coefficiant %/℃ | 0.06 |
| Open Circuit Voltage Temperature Coefficient %/℃ | -0.34 |
| Maximum Power Temperature Coefficient %/℃ | -0.47 |
| Performance Warranty : 90%output ,12 years |
|
|
80%output, 25 years |
| Type Of Module | NB-60-M270W | NB-60-W275W | NB-60-M280W | NB-60-M285W | NB-60-M290W | NB-60-M295W | NB-60-M300W |
| Maximum Power (W) | 270 | 275 | 280 | 285 | 290 | 295 | 300 |
| Tolerance(%) | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% |
| Open Circuit Voltage (V) | 38.1 | 38.2 | 38.4 | 38.5 | 38.6 | 38.7 | 38.8 |
| Short Circuit Current (A) | 9.00 | 9.14 | 9.27 | 9.41 | 8.96 | 9.06 | 9.16 |
| Maximum Power Voltage (V) | 31.5 | 31.6 | 31.7 | 31.8 | 31.9 | 32 | 32.1 |
| Maximum Power Current (A) | 8.57 | 8.70 | 8.83 | 8.96 | 8.57 | 8.7 | 8.83 |
| Module Efficiency (%) | 16.6 | 16.9 | 17.2 | 17.5 | 17.8 | 18.1 | 18.4 |
| Solar Cell Efficiency (%) | 18.88 | 19.23 | 19.58 | 19.93 | 20.28 | 20.63 | 20.98 |
| Series Fuse Rating (A) | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Terminal Box | IP65 | ||||||
| Maximum system voltage (V) | DC1000 | ||||||
| Operating Temperature(℃) | -40℃--85℃ | ||||||
| Dimension | 1640*992*35MM | ||||||
| Weight | 18KG/PCS | ||||||
| Packing | 2 pcs in one carton or 30pcs/ pallet | ||||||
