Niyue® is one of the professional 300-335W Mono Poly solar Module manufacturers and suppliers in China. Our products are CE certified and have in stock of factory, welcome to wholesale 300-335W Mono Poly solar Module from us.
| Short Circuit Current Temperature Coefficiant %/℃ | 0.06 |
| Open Circuit Voltage Temperature Coefficient %/℃ | -0.34 |
| Maximum Power Temperature Coefficient %/℃ | -0.47 |
| Performance Warranty : 90%output ,12 years |
|
|
80%output, 25 years |
| Type Of Module | NB-72-P300W | NB-72-P305W | NB-72-P310W | NB-72-P315W | NB-72-P320W | NB-72-P325W | NB-72-P330W |
| Maximum Power (W) | 300 | 305 | 310 | 315 | 320 | 325 | 330 |
| Tolerance(%) | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% | ±3% |
| Open Circuit Voltage (V) | 43.7 | 43.9 | 44.2 | 44.4 | 44.6 | 45.0 | 45.1 |
| Short Circuit Current (A) | 8.73 | 8.82 | 8.92 | 9.01 | 9.11 | 8.96 | 9.29 |
| Maximum Power Voltage (V) | 36.1 | 36.3 | 36.5 | 36.7 | 36.9 | 37.2 | 37.3 |
| Maximum Power Current (A) | 8.31 | 8.40 | 8.49 | 8.58 | 8.67 | 8.74 | 8.85 |
| Module Efficiency(%) | 15.5 | 15.7 | 16.0 | 16.2 | 16.5 | 16.7 | 17.0 |
| Solar Cell Efficiency(%) | 17.48 | 17.77 | 18.07 | 18.36 | 18.65 | 18.94 | 19.23 |
| Series Fuse Rating (A) | 15 | 15 | 15 | 15 | 15 | 15 | 15 |
| Terminal Box | IP65 | ||||||
| Maximum system voltage (V) | DC1000 | ||||||
| Operating Temperature(℃) | -40℃--85℃ | ||||||
| Dimension | 1956*992*35MM OR 1956*992*40MM | ||||||
| Weight | 22KG/PCS | ||||||
| Packing | 2 pcs in one carton or 26pcs/ pallet | ||||||
